規(guī)格參數
Item Description
CPU
Freescale i.MX6 Solo ARM Cortex A9(1.0 GHz,512KB L2 Cache)
Freescale i.MX6 DualLite ARM Cortex A9(2 x 1.0 GHz,512KB L2 Cache)
Freescale i.MX6 Dual ARM Cortex A9(2 x 1.2 GHz,1MB L2 Cache)
Freescale i.MX6 Quad ARM Cortex A9(4 x 1.2 GHz,1MB L2 Cache
Memor
1 GB LV-DDR3,1056 MT/s, 64 bit data bus widthUp to 2GB LV-DDR3
Mass Storage
eMMC 8GB ,Up to 32GB 1 x SATA II(3GB/s) (only with i.MX6D and i.MX6Q)
Graphics
Integrated in Freescale i.MX6 Series Video (VPU), 2D Graphics (GPU2D) and 3D Graphics (GPU3D), 3D graphics with 4 shaders
up to 200MT/s dual stream 1080p/720p decoder/encoder OpenGL 2.0, OpenVG 1.1 processing unit
Display
1 x HDMI 1.4 Up to 1920x1080 2 x 24bit LVDS 1920x1080
1 x 24bit Parallel RGB Up to WUXGA 1920x1200
HD Video Decode
MPEG2 MP, HP, MPEG4 SP H.264
VC-1
DivX
Ethernet 1 x Gbit Ethernet 10/100/1000M Base-T Interfaces
1 x USB 2.0 OTG 1 x USB 2.0 HOST
1 x SATA II(3GB/s)
1 x PCIe 2.0 (1 lanes)
3 x I2C Bus
2 x SPI Bus
2 x CAN Bus
5 x UART(UART4,5 With HW Flow control)，Support RS485
1 x 5*5Matrix keyboard
1 x HDMI
2 x LVDS(4 Lanes)
1 x I2S
1 x SDIO(Up to 8bit)
1 x SDIO(Up to 4bit)
1 x 24bit Parallel LCD Interface
1 x EIM Bus
1 x MIPI CSI-2(3 Lanes)
1 x 8 Bit Parallel Camera Port
4 x PWM
1 x 10 Bit ADC
N x GPIO
Digital Audio SPDIF Out SPDIF In
Other
Watchdog timer Built-in watchdog reset circuit
Support F-RAM/E2Prom
Operating System
Windows CE 7.0 Linux3.10 Android4.4.2 Operating Temperatur
Extended Consumer Grade :-20°C to +70°C
Industrial Grade: -40°C to +85°C
Storage Temperature -50 °C to +100 °C Humidity operating humidity： 10 to 90% r. H. non cond. Storage humidity： 5 to 95% r. H. non cond.
Power Supply DC 4.0V ± 5% (Typical) Mechanical Dimensions 70 x 43 mm PCBA Height:4.6mm
