System Hardware |
Processor | CPU | Rockchip Quad-core Cortex-A55 up to 2.0 GHz |
GPU | ARM G52 2EE |
NPU | 1 TOPS Supports TensorFlow, Caffe, Tflite, Pytorch, Onnx NN, Android NN etc |
Memory | LPDDR4x | 2/4/8GB |
Storage | eMMC | 32/64/128GB eMMC |
SSD | M.2 |
GPU | ARM G52 2EE | OpenGL ES 1.1, 2.0, and 3.2 |
Vulkan 1.0 and 1.1 |
OpenCL 2.0 Full Profile |
Multimedia | Decoder:4KP60 H.265/H.264/VP9 Encoder:1080P60 H.264/H.265 |
I/O Interfaces |
IO | Serial Port | 2xRS22 1xRS232 |
4xRS485 |
Ethernet | 2xLAN 10/100/1000 Mbps |
CAN | 1xCAN 2.0 |
LED Indicators | 10xLEDs |
USB | 2xUSB HOST3.0 TypeA |
1xUSB HOST2.0 TypeA |
1xUSB OTG 3.0 TypeA |
Audio | 1xHP |
WIFI&BT | 802.11 a/b/g/n ,BT5 |
Display | 2xHDMI 2.0 Out,Support Up to 4Kx2K@60Hz |
Mobile network | 4G(optional) |
Others | Support IR input |
Support Auto power OFF / ON |
Integrated MCU for second watchdog or other special purposes |
Integrated E2Prom/F-RAM |
Power | DC 12V-2A (Type) |
Environment | Operating Temperature | 0~70℃/-25~80℃/-40~85℃ |
Operating Humidity | 10to90%r.H.non cond. |
Storage Temperature | -40~85℃ |
Mechanical | 160(L)x120(W)x36(H)mm |
Operation System | Linux,Ubuntu,Debian,OpenHarmony,Android |
