詳細信息
1 x USB OTG 2.0 （對外）
規格參數
Item
Description
CPU
Rockchip? ARM Cotex-A72+ Cotex-A53六核處理器RK3399（商業級）
Rockchip? ARM Cotex-A72+ Cotex-A53六核處理器RK3399K（寬溫級）
Memory
2 GB LPDDR4,1866 MT/s, 64 bit data bus widthUp to 4GB LP-DDR4
Mass Storage
EMMC 5.1 8/16/32GB
Graphics
3D Graphics Engine :
ARM Mali-T860 GPU core
High performance OpenGL ES1.1/2.0/3.0, OpenCL 1.2, DirectX 11.1
Embedded 4 shader cores with shared hierarchical tiler
Provide MMU and L2 Cache with 256KB size
Image quality using double-precision FP64, and anti-aliasing
10-bit and 16-bit YUV input and output formats
2D Graphics Engine (RGA2)
HD Video Encoder Decoder
Support video encoder for H.264 (BP@level4.0, MP@level4.0, HP@level4.0), MVC and VP8 HEVC Decoder:
Main/Main10 HEVC/H.265 decoder, 4k@60FPS
Support up to 4096x2304 resolution
Display
1 x MIPI 4 LANE, Support Up to 1920x1200@60fps
1 x EDP 2 LANE, Support 1920x1200@30fps
USB 2.0
3x USB HOST 2.0
1x USB HOST 2.0（2G/4G Lte數據模塊）
1x USB HOST 3.0（USB Type-C可選）
1 x USB HOST 2.0（對外）1 x USB OTG 2.0 （對外）
Ethernet
1 x 10/100Mbps Ethernet
Interfaces
2 x MIPI CSI 4 Lanes FPC
1 x EDP FPC
1 x MIPI DSI FPC
1 x I2C CTP
1 x RS485/232
2 x UART(TTL/RS232 , TTL 3.3V/5V Optional)
1 x UART（For RFID Optional）
4 x DI/DO (帶ESD保護)
1 x Wiegand DI (TTL 5V)
1 x Wiegand DO (TTL 5V)
1 x Relay（Support 400V/0.13A AC or DC）
1 x PIR（人體微波感應接口）
1 x White LED
1 x Green LED
1 x IR LED
2 x ADC
2 x Speakers
1 x Microphone
1 x DC Power Port
1 x DC 5V FAN
Other
Watchdog timer
Built-in watchdog reset circuit
Support F-RAM/E2Prom
Operating System
Linux3.1 Android7.1
Operating
Temperature
Consumer Grade : 0°C to +70°C
Extended Grade: -20°C to +85°C
Storage Temperature
-40 °C to +100 °
Humidity
operating humidity： 10 to 90% r. H. non cond.
Storage humidity： 5 to 95% r. H. non cond.
Power Supply
DC 12V ± 5% (Typical)
Mechanical Dimensions
100(L) x 88(W) x 10(H) mm PCBA Height:10mm
