詳細信息
規格參數
Item
Description CPU
Rockchip? ARM Cotex-A17四核處理器RK3288W/K Memory
2 GB LV-DDR3,1333 MT/s, 2 channel 32 bit data bus width Up to 4GB LV-DDR3 Mass Storage
eMMC 8/16GB
Graphics
3D Graphics Engine :
ARM Mali-T764 GPU core
High performance OpenGL ES1.1/2.0/3.0, OpenCL 1.1, DirectX 11(W version only)
Embedded 4 shader cores with shared hierarchical tiler
Provide MMU and L2 Cache with 256KB size
Image quality using double-precision FP64, and anti-aliasing 2D Graphics Engine (RGA2)
HD Video Encoder Decoder
Support video encoder for H.264 (BP@level4.0, MP@level4.0, HP@level4.0), MVC and VP8
HEVC Decoder:
Main/Main10 HEVC/H.265 decoder, 4k@60FPS
Support up to 4096x2304 resolution
Display
1 x MIPI 4 LANE, Support Up to 1080P@60fps
1 x 24/18bit LVDS Support 1280x800@30fps
1 x EDP 2 LANE, Support 1920x1200@30fps
USB 2.0
3x USB HOST 2.0
1x USB HOST 2.0（2G/4G Lte數據模塊）
1 x USB HOST 2.0（對外）
1 x USB OTG 2.0Ethernet
1 x 10/100Mbps Ethernet lnterfaces
1 x LVDS(4 Lanes/1 channel) FPC
1 x EDP FPC
1 x MIPI DSI FPC
1 x I2C CTP
1 x I2C GPIO
1 x RS485/232
2 x UART(TTL/RS232 , TTL 3.3V/5V Optional)
1 x UART（For RFID Optional）
4 x DI/DO (帶ESD保護)
1 x Wiegand DI (TTL 5V)
1 x Wiegand DO (TTL 5V)
1 x Relay（Support 400V/0.13A AC or DC）
1 x PIR（人體微波感應接口）
1 x White LED
1 x Green LED
1 x IR LED
2 x ADC
1 x Speakers
1 x Microphone
1 x DC Power Port
1 x DC 5V FAN
Other
Watchdog timer
Built-in watchdog reset circuit
Support F-RAM/E2Prom
Operating System
Linux4.4
Android7.1
Operating Temperature
Consumer Grade : -20°C to +70°C
Extended Grade: -30°C to +85°C
Storage Temperature
-40 °C to +100 °C
Humidity
operating humidity： 10 to 90% r. H. non cond.
Storage humidity： 5 to 95% r. H. non cond.
Power Supply
DC 12V ± 5% (Typical)
Mechanical
Dimensions
100(L) x 88(W) x 10(H) mm
PCBA Height:10mm
