詳細信息
1 x Green LED
規格參數
Item
Description CPU Rockchip? ARM Cotex-A55四核處理器RK3568 Memory 2 GB LP-DDR4/4X,3200 MT/s, 1 channel 32 bit data bus width Up to 8GB LP-DDR4/4X Mass Storage eMMC 16/32/64GB (Optional) Graphics
3D Graphics Engine :
Mali-G52 1-Core-2EE
Support OpenGL ES 1.1, 2.0, and 3.2
Support Vulkan 1.0 and 1.1
Support OpenCL 2.0 Full Profile
Support 1600Mpix/s fill rate when 800MHz clock frequency
Support 38.4GLOPs when 800MHz clock frequency
HD Video Encoder
Video Encoder
H.264/AVC BP/MP/HP@level4.2，up to 1920x1080@100fps
H.265/HEVC MP@level4.1, up to 1920x1080@100fps (4096x4096@10fps with TILE)
Support YUV/RGB video source with rotation and mirror
HD Video Decoder
Video Decoder
H.265 HEVC/MVC Main10 Profile yuv420@L5.1 up to 4096x2304@60fps
H.264 AVC/MVC Main10 Profile yuv400/yuv420/yuv422/@L5.1 up to 4096x2304@60fps
VP9 Profile0/2 yuv420@L5.1 up to 4096x2304@60fps
VP8 verision2,up to 1920x1088@60fps
VC1 Simple Profile@low, medium, high levels, Main Profile@low, medium, high levels, Advanced Profile@level0~3,up to 1920x1088@60fps
MPEG-4 Simple Profile@L0~6,Advanced Simple Profile@L0~5,up to 1920x1088@60fps
MPEG-2 Main Profile, low, medium and high levels, up to 1920x1088@60fps
MPEG-1 Main Profile, low, medium and high levels, up to 1920x1088@60fps
H.263 Profile0,levels 10-70,up to 720x576@60fps
Display
1 x MIPI DSI 4 Lane, Support Up to 1080P@60fps
2 x 24/18bit LVDS Support 1920x1200@60fps
1 x EDP1.3 4 Lane, Support Up to 2560x1600 @60fps
1 x HDMI 2.0 Out , Support Up to 4096x2340 @60fpsUSB 2.0
5 x USB HOST 2.0 (PH2.0插座)
1 x USB HOST 2.0（Mini Pcie 4G LTE數據模塊）
1 x USB HOST 3.0 Type-A
1 x USB OTG 3.0 Type-A
1 x USB HOST 2.0 Type-A
Ethernet
1 x 10/100/1000Mbps Ethernet
1 x POE PWRInterfaces
1 x DUAL LVDS(4 Lanes/1 channel)
1 x EDP V1.3
1 x MIPI DSI (4 Lanes)
1 x MIPI CSI (4 Lanes)
2 x I2C CTP
3 x RS232
1 x RS485
3 x UART TTL
1 x CAN 2.0
1 x UART（For Debug）
4 x DI/DO
1 x Relay（Support 400V/0.13A AC or DC）
1 x PIR（人體微波感應接口）
1 x White LED
1 x Green LED
1 x Red LED
2 x ADC
1 x HP
2 x Speakers
1 x Microphone
1 x DC Power Port
1 x DC 12V IN
Other
Watchdog timer
Built-in watchdog reset circuit
Support F-RAM/E2Prom
Operating System Linux 4.4 Android 11.0
Operating Temperature Consumer Grade : 0°C to +70°C
Extended Grade: -20°C to +80°C
Storage Temperature
-40 °C to +100 °C Humidity
operating humidity： 10 to 90% r. H. non cond.
Storage humidity： 5 to 95% r. H. non cond.
Power Supply DC 12V ± 5% (Typical)，Imax 3A Mechanical Dimensions
142(L) x 95(W) x 15(H) mm
PCBA Height:10mm
