詳細信息
規格參數
Item Description CPU Rockchip? ARM Cotex-A17四核處理器RK3288W/K Memory 2 GB LV-DDR3,1333 MT/s, 2 channel 32 bit data bus width Up to 4GB LV-DDR3 Mass Storage eMMC 16/32GB (Optional) Graphics
3D Graphics Engine :
ARM Mali-T764 GPU core
High performance OpenGL ES1.1/2.0/3.0, OpenCL 1.1, DirectX 11(W version only)
Embedded 4 shader cores with shared hierarchical tiler
Provide MMU and L2 Cache with 256KB size
Image quality using double-precision FP64, and anti-aliasing 2D Graphics Engine (RGA2)
HD Video Encoder
Decoder
Support video encoder for H.264 (BP@level4.0, MP@level4.0, HP@level4.0), MVC and VP8
HEVC Decoder:
Main/Main10 HEVC/H.265 decoder, 4k@60FPS
Support up to 4096x2304 resolution
Display
1 x MIPI DSI 4 Lane, Support Up to 1080P@60fps 2 x 24/18bit LVDS Support 1920x1080@60fps
1 x EDP1.1 4 Lane, Support Up to 4Kx2K @30fps
1 x EDP1.2 4 Lane, Support Up to 4Kx2K @60fps
USB 2.05 x USB HOST 2.0 1 x USB HOST 2.0（Mini Pcie 2G/4G LTE數據模塊）
2 x USB HOST 2.0 Type-A（對外）
1 x USB OTG 2.0 Type-A（對外）
Ethernet 1 x 10/100/1000Mbps Ethernet 1 x POE
Interfaces
2 x LVDS(4 Lanes/1 channel)
2 x EDP
1 x MIPI DSI
1 x MIPI CSI
2 x I2C CTP
2 x RS232/TTL
1 x RS485/TTL
1 x CAN 2.0
1 x UART（For Debug）
4 x DI/DO
1 x Relay（Support 400V/0.13A AC or DC）1 x PIR（人體微波感應接口）
1 x White LED
1 x Green LED
1 x IR LED
2 x ADC
1 x HP
2 x Speakers
1 x Microphone
1 x DC Power Port
1 x DC 5V FAN
Othe
Watchdog timer Built-in watchdog reset circuit
Support F-RAM/E2Prom
Operating System Linux3.10 Android7.1 Operating Temperature Consumer Grade : 0°C to +70°C Extended Grade: -20°C to +85°C
Storage
Temperature
-40 °C to +100 °C
Humidity operating humidity： 10 to 90% r. H. non cond. Storage humidity： 5 to 95% r. H. non cond.
Power Supply DC 12V ± 5% (Typical) Mechanical Dimensions 142(L) x 95(W) x 15(H) mm PCBA Height:10mm
