詳細信息
規格參數
Item
Description
CPU Rockchip? ARM Cotex-A76*4+ ARM Cotex-A55*4八核處理器RK3588
Memory 4/8/16 /32GB (Optional)LP-DDR4/4X,3200 MT/s, 2 channel 32bit data bus width Up to 32GB LP-DDR4/4X
Mass Storage eMMC 5.1 16/32/64GB (Optional)
Graphics
3D Graphics Engine
Mali-G610 MP4
Support OpenGL ES 1.1, 2.0, and 3.2
Support Vulkan 1.1 and 1.2
Support OpenCL 2.2 Full Profile
Support 1600Mpix/s fill rate when 800MHz clock frequency
Support 38.4GLOPs when 800MHz clock frequency
HD Video Encoder
Real-time H.265/H.264 video encoding
Support up to 8K@30fps
Multi-channel encoder in parallel for less resolution
HD Video Decoder
Real-time video decoder of MPEG-1, MPEG-2, MPEG-4, H.263, H.264, H.265, VC-1, VP9, VP8, MVC, AV1
MMU Embedded
Multi-channel decoder in parallel for less resolution
H.264 AVC/MVC Main10 L6.0 : 8K@30fps (7680x4320)②
VP9 Profile0/2 L6.1 : 8K@60fps (7680x4320)
H.265 HEVC/MVC Main10 L6.1 : 8K@60fps (7680x4320)
AVS2 Profile0/2 L10.2.6 : 8K@60fps (7680x4320)
AV1 Main Profile 8/10bit L5.3 : 4K@60fps (3840x2160)
MPEG-2 up to MP : 1080p@60fps (1920x1088)
VC-1 up to AP level 3 : 1080p@60fps (1920x1088)
VP8 version2 : 1080p@60fps (1920x1088)
Neural Process Unit
Neural network acceleration engine with processing performance up to 6 TOPS
Include triple NPU core, and support triple core co-work, dual core co-work, and work independently
Support integer 4, integer 8, integer 16, float 16, Bfloat 16 and tf32 operation
Support deep learning frameworks: TensorFlow, Caffe, Tflite, Pytorch, Onnx NN, Android NN, etc.
Display Interface
2 x MIPI DSI 4 Lane, Support Up to 4K@60Hz
2 x DP1.4 , Support Up to 8K@30Hz
2 x EDP1.3 4 Lane, Support Up to 4K@60Hz
2 x HDMI 2.1 Out , Support Up to 8K @60Hz
1 x BT1120, Support up to 1920x1080@60Hz
USB Port
2 x USB 2.0 HOST
1 x USB 3.1 HOST
2 x USB 3.1 OTG, Support USB 3.1 Type-C
Connectivity Interfaces
2 x SDIO3.0 3 x PCIe2.1, Support one lane
1 x PCIe3.0, Support two lane
3 x SATA3.1
5 x I2C
3 x SPI
10 x UART
3 x CAN 2.0
16 x PWM
N x GPIO
3 x ADC
4 x I2S/PCM
1 x PDM, Up to 8 channels
1 x Green LED
1 x Reset button
1 x Poweron button
1 x Recovery button
Ethernet 2 x RGMII/RMII, Support 10/100/1000 Mbps Ehernet Other
Watchdog timer
Built-in watchdog reset circuit
Support F-RAM/E2Prom
Operating System Linux 5.x Android 12.0
Operating Temperature
Consumer Grade : 0°C to +70°C
Extended Grade: -20°C to +85°C
Storage Temperature -40 °C to +100 °C
Humidity
operating humidity： 10 to 90% r. H. non cond.
Storage humidity： 5 to 95% r. H. non cond.
Power Supply DC 4.0V ± 5% (Typical)，Imax 5.0A
Mechanical Dimensions
82(L) x 52(W) x 5(H) mm
PCBA Height:5mm
